RJ Connector

RJ-11 non-international standard: 4-pin telephone line connection plug: It has six wires, but usually only four are used. The RJ-11 interface is the jack into which the ordinary flat wiring of the fixed telephone in your home or office is inserted. In addition, the computer that dials the Internet using a telephone line is to insert the telephone line into the RJ-11 jack of the modem.
RJ-45 international standard: 8-core Ethernet cable connection plug, it is the plug at both ends of your network twisted pair.


Current Rating : 1.5 Ampere

Insulation Resistance : 1000 MΩ Min

Dielectric Withstanding : 1000 V

Contact Resistance : 30 mΩ Max


Mating Force : 30N Max

Unmating Force: 50N Min

Durability : 750 Cycles


Housing : Nylon/PBT UL 94V-0

Contact : Phosphor Bronze


Contact : Gold plated on contact area Nickel plated overall

Environment Characteristics

Operating temperature : -40℃ to +85℃
